Please contact us for more photos of 505006-0810
| Part Number | 505006-0810 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 669980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board PL 4Power 4Signal POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 505006-0810 |
| Datasheet download |  505006-0810.pdf |
| Part Number | 505006-0810 |
|---|---|
| Number of Rows | 2 |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Lead Finish | Gold Over Nickel |
| Maximum Contact Resistance | MOhm |
| Operating Temperature | -40 to 85 °C |
| Housing Material | Liquid Crystal Polymer |
| Gender | PL |
| Number of Contacts | 4Power/4Signal |
| Termination Method | Solder |
| Pitch | 0.4 mm |
| Type | Board to Board |
| Product Dimensions | 3.3 x 1.76 x 0.63 |
| Mounting | Surface Mount |
| Housing Color | Black |
| Body Orientation | Straight |
| Pin Count | 8 |
| Maximum Current Rating | 3|0.3 A |
| Product Depth | 1.76 mm |
| Product Height | 0.63 mm |
| Product Length | 3.3 mm |
| Replacement Part Number | PART-505006-0810 |
| Weight | Contact us |
| Country of Origin | - |
