Please contact us for more photos of 505151-0700
| Part Number | 505151-0700 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 864880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Housing RCP 7 POS 2mm ST Cable Mount Bag |
| Category | Connectors |
| Family | Connector Discrete Wire Housing |
| ROHS Compliant | Yes |
| MSL Level | 505151-0700 |
| Datasheet download |  505151-0700.pdf |
| Part Number | 505151-0700 |
|---|---|
| Rad Hard | No |
| Pitch | 2 mm |
| Mounting | Cable Mount |
| Body Orientation | Straight |
| Operating Temperature | -40 to 125 °C |
| Housing Color | Black |
| Package Dimensions | 17.8 x 7.55 x 6.2 mm |
| Number of Rows | 1 |
| Number of Contacts | 7 |
| Type | Housing |
| Housing Material | Polyester Alloy |
| Gender | RCP |
| Product Depth | 7.55 mm |
| Product Height | 6.2 mm |
| Product Length | 17.8 mm |
| Replacement Part Number | PART-505151-0700 |
| Weight | Contact us |
| Country of Origin | - |
