Please contact us for more photos of BSC340N08NS3 G
| Part Number | BSC340N08NS3 G |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 228730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 80V 7A 8-Pin TDSON T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | BSC340N08NS3 G |
| Datasheet download |  BSC340N08NS3 G.pdf |
| Part Number | BSC340N08NS3 G |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 260 |
| Maximum Drain Source Voltage | 80 V |
| Typical Fall Time | 2 ns |
| Maximum Gate Source Voltage | ±20 V |
| Channel Mode | Enhancement |
| Supplier Package | TDSON |
| Typical Rise Time | 3 ns |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Channel Type | N |
| Typical Turn-On Delay Time | 8 ns |
| Operating Temperature | -55 to 150 °C |
| Product Dimensions | 5.35(Max) x 6.1(Max) x 1.1(Max) |
| Lead Finish | Tin |
| Typical Turn-Off Delay Time | 11 ns |
| RDS-on | 34@10V mOhm |
| Pin Count | 8 |
| Maximum Continuous Drain Current | 7 A |
| Package | 8TDSON |
| Replacement Part Number | PART-BSC340N08NS3 G |
| Weight | Contact us |
| Country of Origin | - |
