| Part Number | CSD18501Q5A |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 878090 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 40V 22A 8-Pin SON EP T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | CSD18501Q5A |
| Datasheet download |  CSD18501Q5A.pdf |
| Part Number | CSD18501Q5A |
|---|---|
| Product Dimensions | 4.9 x 5.75 x 1 mm |
| Supplier Package | SON EP |
| Typical Rise Time | 10 ns |
| Operating Temperature | -55 to 150 °C |
| Rad Hard | No |
| Typical Fall Time | 3.4 ns |
| RDS-on | 3.2@10V mOhm |
| Max Processing Temp | 260 |
| Typical Turn-Off Delay Time | 20 ns |
| Typical Turn-On Delay Time | 4.7 ns |
| Channel Mode | Enhancement |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Channel Type | N |
| Maximum Drain Source Voltage | 40 V |
| MSL Level | 1 |
| Pin Count | 8 |
| Maximum Continuous Drain Current | 22 A |
| Maximum Gate Source Voltage | ±20 V |
| Package | 8SON EP |
| Replacement Part Number | PART-CSD18501Q5A |
| Weight | Contact us |
| Country of Origin | - |
