CSD19506KCS Texas Instruments

Please contact us for more photos of CSD19506KCS

Part Number	CSD19506KCS
Manufacturer	Texas Instruments
Quantity in stock	413830 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans MOSFET N-CH 80V 273A 3-Pin TO-220 Tube
Category	Discrete Semiconductor
Family	Transistor
ROHS Compliant	Yes
MSL Level	CSD19506KCS
Datasheet download	CSD19506KCS.pdf

Request Quotation for CSD19506KCS

CSD19506KCS Specifications

Part Number	CSD19506KCS
Rad Hard	No
Maximum Drain Source Voltage	80 V
Pin Count	3
Maximum Continuous Drain Current	273 A
Operating Temperature	-55 to 175 °C
Supplier Package	TO-220
Channel Mode	Enhancement
Mounting	Through Hole
Maximum Gate Source Voltage	±20 V
RDS-on	2.3@10V mOhm
Product Dimensions	10.67(Max) x 4.7(Max) x 9.25(Max)
Typical Rise Time	11 ns
Typical Turn-On Delay Time	19 ns
Screening Level	Military
Typical Fall Time	10 ns
Typical Turn-Off Delay Time	30 ns
Channel Type	N
Package	3TO-220
Replacement Part Number	PART-CSD19506KCS
Weight	Contact us
Country of Origin	-
