CSD25402Q3A Texas Instruments

Please contact us for more photos of CSD25402Q3A

Part Number	CSD25402Q3A
Manufacturer	Texas Instruments
Quantity in stock	597530 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans MOSFET P-CH 20V 72A 8-Pin VSON T R
Category	Discrete Semiconductor
Family	Transistor
ROHS Compliant	Yes
MSL Level	CSD25402Q3A
Datasheet download	CSD25402Q3A.pdf

Request Quotation for CSD25402Q3A

CSD25402Q3A Specifications

Part Number	CSD25402Q3A
Rad Hard	No
Operating Temperature	-55 to 125 °C
Channel Type	P
Typical Turn-Off Delay Time	25 ns
Typical Fall Time	12 ns
Typical Rise Time	7 ns
Mounting	Surface Mount
MSL Level	1
Typical Turn-On Delay Time	10 ns
Maximum Continuous Drain Current	72 A
RDS-on	[email protected] mOhm
Maximum Drain Source Voltage	20 V
Lead Finish	Tin
Pin Count	8
Max Processing Temp	260
Channel Mode	Enhancement
Supplier Package	VSON
Screening Level	Military
Product Dimensions	3.25(Max) x 3.1(Max) x 0.9(Max)
Maximum Gate Source Voltage	±12 V
Package	8VSON
Replacement Part Number	PART-CSD25402Q3A
Weight	Contact us
Country of Origin	-
