DMN5L06DWK-7 Diodes Incorporated

DMN5L06DWK-7 Images

Please contact us for more photos of DMN5L06DWK-7

Part Number DMN5L06DWK-7
Manufacturer Diodes Incorporated
Quantity in stock 557210 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 50V 0.305A 6-Pin SOT-363 T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level DMN5L06DWK-7
Datasheet download DMN5L06DWK-7.pdf
Request Quotation for DMN5L06DWK-7

DMN5L06DWK-7 Specifications

Part Number DMN5L06DWK-7
Lead Finish Matte Tin
Rad Hard No
Pin Count 6
Maximum Gate Source Voltage ±20 V
MSL Level 1
Mounting Surface Mount
Channel Mode Enhancement
Channel Type N
Maximum Continuous Drain Current 0.305 A
Operating Temperature -65 to 150 °C
Max Processing Temp 260
Supplier Package SOT-363
RDS-on 2000@5V mOhm
Product Dimensions 2.2 x 1.35 x 1 mm
Maximum Drain Source Voltage 50 V
Package 6SOT-363
Replacement Part Number PART-DMN5L06DWK-7
Weight Contact us
Country of Origin -
