DMN62D0LFB-7 Diodes Incorporated

Please contact us for more photos of DMN62D0LFB-7

Part Number	DMN62D0LFB-7
Manufacturer	Diodes Incorporated
Quantity in stock	815480 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans MOSFET N-CH 60V 0.1A 3-Pin DFN T R
Category	Discrete Semiconductor
Family	Transistor
ROHS Compliant	Yes
MSL Level	DMN62D0LFB-7
Datasheet download	DMN62D0LFB-7.pdf

Request Quotation for DMN62D0LFB-7

DMN62D0LFB-7 Specifications

Part Number	DMN62D0LFB-7
Product Dimensions	1 x 0.6 x 0.47 mm
Channel Type	N
Maximum Continuous Drain Current	0.1 A
Typical Turn-On Delay Time	3.4 ns
Typical Fall Time	16.3 ns
RDS-on	2000@4V mOhm
Typical Turn-Off Delay Time	26.4 ns
Supplier Package	DFN
Channel Mode	Enhancement
Typical Rise Time	3.4 ns
Operating Temperature	-55 to 150 °C
Maximum Gate Source Voltage	±20 V
Maximum Drain Source Voltage	60 V
Pin Count	3
Mounting	Surface Mount
Lead Finish	Gold
Rad Hard	No
Max Processing Temp	260
MSL Level	1
Package	3DFN
Replacement Part Number	PART-DMN62D0LFB-7
Weight	Contact us
Country of Origin	-
