FDD390N15A Fairchild Semiconductor

FDD390N15A Images

Please contact us for more photos of FDD390N15A

Part Number FDD390N15A
Manufacturer Fairchild Semiconductor
Quantity in stock 161640 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 150V 25A 3-Pin(2+Tab) DPAK T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level FDD390N15A
Datasheet download FDD390N15A.pdf
Request Quotation for FDD390N15A

FDD390N15A Specifications

Part Number FDD390N15A
Maximum Gate Source Voltage ±20 V
Typical Rise Time 10 ns
Typical Fall Time 5 ns
Typical Turn-On Delay Time 14 ns
Channel Type N
Operating Temperature -55 to 150 °C
Channel Mode Enhancement
Maximum Drain Source Voltage 150 V
Pin Count 3
Product Dimensions 6.73 x 6.22 x 2.39 mm
Rad Hard No
Typical Turn-Off Delay Time 20 ns
RDS-on 40@10V mOhm
Mounting Surface Mount
Max Processing Temp 260
Lead Finish Matte Tin
MSL Level 1
Supplier Package DPAK
Maximum Continuous Drain Current 25 A
Package 3DPAK
Replacement Part Number PART-FDD390N15A
Weight Contact us
Country of Origin -
