Please contact us for more photos of IPB010N06N
| Part Number | IPB010N06N |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 128600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 60V 180A 7-Pin TO-263 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IPB010N06N |
| Datasheet download |  IPB010N06N.pdf |
| Part Number | IPB010N06N |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Product Dimensions | 10.31(Max) x 9.45(Max) x 4.57(Max) |
| RDS-on | 1@10V mOhm |
| Rad Hard | No |
| MSL Level | 1 |
| Typical Rise Time | 36 ns |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Maximum Gate Source Voltage | ±20 V |
| Maximum Drain Source Voltage | 60 V |
| Pin Count | 7 |
| Channel Mode | Enhancement |
| Typical Fall Time | 23 ns |
| Channel Type | N |
| Typical Turn-Off Delay Time | 74 ns |
| Supplier Package | TO-263 |
| Maximum Continuous Drain Current | 180 A |
| Typical Turn-On Delay Time | 37 ns |
| Package | 7TO-263 |
| Replacement Part Number | PART-IPB010N06N |
| Weight | Contact us |
| Country of Origin | - |
