Please contact us for more photos of IPP030N10N5
| Part Number | IPP030N10N5 |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 431690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 100V 120A 3-Pin TO-220 Tube |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IPP030N10N5 |
| Datasheet download |  IPP030N10N5.pdf |
| Part Number | IPP030N10N5 |
|---|---|
| Typical Turn-Off Delay Time | 52 ns |
| Operating Temperature | -55 to 175 °C |
| Mounting | Through Hole |
| Pin Count | 3 |
| Maximum Continuous Drain Current | 120 A |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Typical Rise Time | 15 ns |
| Maximum Gate Source Voltage | ±20 V |
| Typical Fall Time | 17 ns |
| Channel Mode | Enhancement |
| Supplier Package | TO-220 |
| RDS-on | 3@10V mOhm |
| Typical Turn-On Delay Time | 25 ns |
| Product Dimensions | 10.36(Max) x 4.57(Max) x 9.45(Max) |
| Channel Type | N |
| Maximum Drain Source Voltage | 100 V |
| Package | 3TO-220 |
| Replacement Part Number | PART-IPP030N10N5 |
| Weight | Contact us |
| Country of Origin | - |
