Please contact us for more photos of IPT015N10N5
| Part Number | IPT015N10N5 |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 220420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 100V 300A 8-Pin HSOF T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IPT015N10N5 |
| Datasheet download |  IPT015N10N5.pdf |
| Part Number | IPT015N10N5 |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Rad Hard | No |
| Maximum Continuous Drain Current | 300 A |
| Typical Fall Time | 30 ns |
| MSL Level | 1 |
| Typical Rise Time | 30 ns |
| Mounting | Surface Mount |
| RDS-on | 1.5@10V mOhm |
| Typical Turn-Off Delay Time | 85 ns |
| Pin Count | 8 |
| Maximum Gate Source Voltage | 20 V |
| Maximum Drain Source Voltage | 100 V |
| Channel Mode | Enhancement |
| Typical Turn-On Delay Time | 36 ns |
| Product Dimensions | 10.1(Max) x 11.48(Max) x 2.4(Max) |
| Supplier Package | HSOF |
| Channel Type | N |
| Package | 8HSOF |
| Replacement Part Number | PART-IPT015N10N5 |
| Weight | Contact us |
| Country of Origin | - |
