Please contact us for more photos of IPW60R190P6FKSA1
| Part Number | IPW60R190P6FKSA1 |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 322500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 650V 20.2A 3-Pin TO-247 Tube |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IPW60R190P6FKSA1 |
| Datasheet download |  IPW60R190P6FKSA1.pdf |
| Part Number | IPW60R190P6FKSA1 |
|---|---|
| Mounting | Through Hole |
| Pin Count | 3 |
| Typical Rise Time | 8 ns |
| Rad Hard | No |
| Maximum Drain Source Voltage | 650 V |
| Typical Fall Time | 7 ns |
| Typical Turn-Off Delay Time | 45 ns |
| MSL Level | 1 |
| Max Processing Temp | 260 |
| Lead Finish | Tin Over Nickel |
| Maximum Gate Source Voltage | 20 V |
| Channel Mode | Enhancement |
| Typical Turn-On Delay Time | 15 ns |
| Operating Temperature | -55 to 150 °C |
| Channel Type | N |
| Supplier Package | TO-247 |
| Maximum Continuous Drain Current | 20.2 A |
| RDS-on | 0.19@10V Ohm |
| Product Dimensions | 10.65(Max) x 4.9(Max) x 9.83(Max) |
| Package | 3TO-247 |
| Replacement Part Number | PART-IPW60R190P6FKSA1 |
| Weight | Contact us |
| Country of Origin | - |
