IRF7413PBF Infineon

IRF7413PBF Images

Please contact us for more photos of IRF7413PBF

Part Number IRF7413PBF
Manufacturer Infineon
Quantity in stock 358290 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 30V 13A 8-Pin SOIC T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level IRF7413PBF
Datasheet download IRF7413PBF.pdf
Request Quotation for IRF7413PBF

IRF7413PBF Specifications

Part Number IRF7413PBF
Product Dimensions 5 x 4 x 1.5 mm
Pin Count 8
Maximum Gate Source Voltage ±20 V
Typical Rise Time 50 ns
Channel Mode Enhancement
Maximum Continuous Drain Current 13 A
Typical Fall Time 46 ns
Operating Temperature -55 to 150 °C
Channel Type N
Maximum Drain Source Voltage 30 V
Typical Turn-Off Delay Time 52 ns
Typical Turn-On Delay Time 8.6 ns
Rad Hard No
Supplier Package SOIC
RDS-on 11@10V mOhm
Mounting Surface Mount
MSL Level 1
Lead Finish Matte Tin
Max Processing Temp 260|300
Package 8SOIC
Replacement Part Number PART-IRF7413PBF
Weight Contact us
Country of Origin -
