Please contact us for more photos of IRFB3077PBF
| Part Number | IRFB3077PBF |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 580830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 75V 210A 3-Pin(3+Tab) TO-220AB |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRFB3077PBF |
| Datasheet download |  IRFB3077PBF.pdf |
| Part Number | IRFB3077PBF |
|---|---|
| Maximum Drain Source Voltage | 75 V |
| Maximum Gate Source Voltage | ±20 V |
| RDS-on | 3.3@10V mOhm |
| Lead Finish | Matte Sn annealed|Matte Sn |
| Typical Turn-On Delay Time | 25 ns |
| Channel Mode | Enhancement |
| Supplier Package | TO-220AB |
| Channel Type | N |
| Operating Temperature | -55 to 175 °C |
| Mounting | Through Hole |
| Pin Count | 3 |
| Typical Turn-Off Delay Time | 69 ns |
| Rad Hard | No |
| Typical Rise Time | 87 ns |
| Typical Fall Time | 95 ns |
| Max Processing Temp | 260|300 |
| Product Dimensions | 10.66 x 4.82 x 9.02 mm |
| Maximum Continuous Drain Current | 210 A |
| MSL Level | 1 |
| Package | 3TO-220AB |
| Replacement Part Number | PART-IRFB3077PBF |
| Weight | Contact us |
| Country of Origin | - |
