Please contact us for more photos of IRFB3207PBF
| Part Number | IRFB3207PBF |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 422840 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 75V 170A 3-Pin(3+Tab) TO-220AB |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRFB3207PBF |
| Datasheet download |  IRFB3207PBF.pdf |
| Part Number | IRFB3207PBF |
|---|---|
| Channel Mode | Enhancement |
| Channel Type | N |
| Product Dimensions | 10.67 x 4.83 x 9.02 mm |
| Supplier Package | TO-220AB |
| Maximum Gate Source Voltage | ±20 V |
| Maximum Drain Source Voltage | 75 V |
| Operating Temperature | -55 to 175 °C |
| Mounting | Through Hole |
| Pin Count | 3 |
| Typical Turn-Off Delay Time | 68 ns |
| RDS-on | 4.5@10V mOhm |
| Rad Hard | No |
| Typical Fall Time | 74 ns |
| Typical Turn-On Delay Time | 29 ns |
| Max Processing Temp | 260|300 |
| Typical Rise Time | 120 ns |
| Maximum Continuous Drain Current | 170 A |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Package | 3TO-220AB |
| Replacement Part Number | PART-IRFB3207PBF |
| Weight | Contact us |
| Country of Origin | - |
