Please contact us for more photos of IRL3713STRLPBF
| Part Number | IRL3713STRLPBF |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 729520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 30V 260A 3-Pin(2+Tab) D2PAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRL3713STRLPBF |
| Datasheet download |  IRL3713STRLPBF.pdf |
| Part Number | IRL3713STRLPBF |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Product Dimensions | 10.67 x 9.65 x 4.83 mm |
| Pin Count | 3 |
| Rad Hard | No |
| Typical Turn-Off Delay Time | 40 ns |
| Mounting | Surface Mount |
| Maximum Continuous Drain Current | 260 A |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Max Processing Temp | 260|300 |
| Supplier Package | D2PAK |
| Maximum Gate Source Voltage | ±20 V |
| Channel Mode | Enhancement |
| Maximum Drain Source Voltage | 30 V |
| Typical Fall Time | 57 ns |
| Channel Type | N |
| Typical Turn-On Delay Time | 16 ns |
| Typical Rise Time | 160 ns |
| RDS-on | 3@10V mOhm |
| Package | 3D2PAK |
| Replacement Part Number | PART-IRL3713STRLPBF |
| Weight | Contact us |
| Country of Origin | - |
