Please contact us for more photos of IRLB3036PBF
| Part Number | IRLB3036PBF |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 338230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 60V 270A 3-Pin(3+Tab) TO-220AB |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRLB3036PBF |
| Datasheet download |  IRLB3036PBF.pdf |
| Part Number | IRLB3036PBF |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Mounting | Through Hole |
| Pin Count | 3 |
| Typical Fall Time | 110 ns |
| Rad Hard | No |
| MSL Level | 1 |
| Max Processing Temp | 260|300 |
| Maximum Continuous Drain Current | 270 A |
| RDS-on | 2.4@10V mOhm |
| Maximum Gate Source Voltage | ±16 V |
| Typical Turn-On Delay Time | 66 ns |
| Channel Mode | Enhancement |
| Supplier Package | TO-220AB |
| Typical Rise Time | 220 ns |
| Product Dimensions | 10.67 x 4.83 x 9.02 mm |
| Lead Finish | Matte Sn annealed|Matte Sn |
| Channel Type | N |
| Maximum Drain Source Voltage | 60 V |
| Typical Turn-Off Delay Time | 110 ns |
| Package | 3TO-220AB |
| Replacement Part Number | PART-IRLB3036PBF |
| Weight | Contact us |
| Country of Origin | - |
