IRLML5103TRPBF Infineon

Please contact us for more photos of IRLML5103TRPBF

Part Number	IRLML5103TRPBF
Manufacturer	Infineon
Quantity in stock	466150 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Trans MOSFET P-CH 30V 0.76A 3-Pin Micro T R
Category	Discrete Semiconductor
Family	Transistor
ROHS Compliant	Yes
MSL Level	IRLML5103TRPBF
Datasheet download	IRLML5103TRPBF.pdf

Request Quotation for IRLML5103TRPBF

IRLML5103TRPBF Specifications

Part Number	IRLML5103TRPBF
Maximum Gate Source Voltage	±20 V
Supplier Package	Micro
Channel Mode	Enhancement
Product Dimensions	3.04 x 1.4 x 1.02 mm
Typical Rise Time	8.2 ns
Maximum Drain Source Voltage	30 V
Operating Temperature	-55 to 150 °C
Maximum Continuous Drain Current	0.76 A
Pin Count	3
Rad Hard	No
Typical Turn-On Delay Time	10 ns
Channel Type	P
RDS-on	600@10V mOhm
Lead Finish	Matte Tin
Mounting	Surface Mount
Max Processing Temp	260\|300
MSL Level	1
Typical Turn-Off Delay Time	23 ns
Typical Fall Time	16 ns
Package	3Micro
Replacement Part Number	PART-IRLML5103TRPBF
Weight	Contact us
Country of Origin	-
