Please contact us for more photos of NTD5862NT4G
| Part Number | NTD5862NT4G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 116590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 60V 98A 3-Pin(2+Tab) DPAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | NTD5862NT4G |
| Datasheet download |  NTD5862NT4G.pdf |
| Part Number | NTD5862NT4G |
|---|---|
| Lead Finish | Matte Tin |
| Pin Count | 3 |
| Maximum Gate Source Voltage | ±20 V |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Rad Hard | No |
| Channel Type | N |
| Product Dimensions | 6.73 x 6.22 x 2.38 mm |
| Typical Rise Time | 70 ns |
| Typical Turn-On Delay Time | 18 ns |
| Typical Fall Time | 60 ns |
| Maximum Drain Source Voltage | 60 V |
| Typical Turn-Off Delay Time | 35 ns |
| Channel Mode | Enhancement |
| RDS-on | 5.7@10V mOhm |
| Maximum Continuous Drain Current | 98 A |
| Max Processing Temp | 260 |
| Supplier Package | DPAK |
| Operating Temperature | -55 to 175 °C |
| Package | 3DPAK |
| Replacement Part Number | PART-NTD5862NT4G |
| Weight | Contact us |
| Country of Origin | - |
