| Part Number | NTR4503NT1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 556370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 30V 2A 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | NTR4503NT1G |
| Datasheet download |  NTR4503NT1G.pdf |
| Part Number | NTR4503NT1G |
|---|---|
| Pin Count | 3 |
| Max Processing Temp | 260 |
| Channel Type | N |
| Channel Mode | Enhancement |
| Maximum Drain Source Voltage | 30 V |
| RDS-on | 110@10V mOhm |
| Product Dimensions | 2.9 x 1.3 x 0.94 mm |
| Maximum Gate Source Voltage | ±20 V |
| Typical Rise Time | 5.8|6.7 ns |
| Typical Fall Time | 1.6|1.8 ns |
| Typical Turn-On Delay Time | 5.8|4.8 ns |
| Typical Turn-Off Delay Time | 14|13.6 ns |
| Operating Temperature | -55 to 150 °C |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Maximum Continuous Drain Current | 2 A |
| Supplier Package | SOT-23 |
| Mounting | Surface Mount |
| Rad Hard | No |
| Package | 3SOT-23 |
| Replacement Part Number | PART-NTR4503NT1G |
| Weight | Contact us |
| Country of Origin | - |
