PMPB11EN,115 Nexperia

PMPB11EN,115 Images

Please contact us for more photos of PMPB11EN,115

Part Number PMPB11EN,115
Manufacturer Nexperia
Quantity in stock 743130 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 30V 9A 6-Pin DFN-MD EP T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level PMPB11EN,115
Datasheet download PMPB11EN,115.pdf
Request Quotation for PMPB11EN,115

PMPB11EN,115 Specifications

Part Number PMPB11EN,115
Product Dimensions 2.1 x 2.1 x 0.65 mm
Max Processing Temp 260
Supplier Package DFN-MD EP
RDS-on 14.5@10V mOhm
Maximum Gate Source Voltage 20 V
Typical Rise Time 10 ns
Lead Finish Tin
Pin Count 6
Typical Fall Time 9 ns
Operating Temperature -55 to 150 °C
Channel Mode Enhancement
Maximum Continuous Drain Current 9 A
Channel Type N
Maximum Drain Source Voltage 30 V
Typical Turn-On Delay Time 9 ns
MSL Level 1
Typical Turn-Off Delay Time 17 ns
Mounting Surface Mount
Rad Hard No
Package 6DFN-MD EP
Replacement Part Number PART-PMPB11EN,115
Weight Contact us
Country of Origin -
