Please contact us for more photos of RRF015P03GTL
| Part Number | RRF015P03GTL |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 350590 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET P-CH 30V \u00b11.5A 3-Pin SOT-323T T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | RRF015P03GTL |
| Datasheet download |  RRF015P03GTL.pdf |
| Part Number | RRF015P03GTL |
|---|---|
| Typical Turn-On Delay Time | 12 ns |
| Channel Mode | Enhancement |
| Maximum Drain Source Voltage | 30 V |
| Operating Temperature | -55 to 150 °C |
| Maximum Gate Source Voltage | ±20 V |
| Maximum Continuous Drain Current | ±1.5 A |
| Pin Count | 3 |
| RDS-on | 160@10V mOhm |
| Typical Rise Time | 8 ns |
| Rad Hard | No |
| Channel Type | P |
| Typical Turn-Off Delay Time | 40 ns |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Product Dimensions | 2.1(Max) x 1.8(Max) x 0.82(Max) |
| Typical Fall Time | 13 ns |
| Supplier Package | SOT-323T |
| Package | 3SOT-323T |
| Replacement Part Number | PART-RRF015P03GTL |
| Weight | Contact us |
| Country of Origin | - |
