Please contact us for more photos of SPD08N50C3
| Part Number | SPD08N50C3 |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 144150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 500V 7.6A 3-Pin TO-252 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | SPD08N50C3 |
| Datasheet download |  SPD08N50C3.pdf |
| Part Number | SPD08N50C3 |
|---|---|
| Maximum Gate Source Voltage | ±20 V |
| Typical Rise Time | 5 ns |
| Channel Mode | Enhancement |
| Operating Temperature | -55 to 150 °C |
| Channel Type | N |
| Pin Count | 3 |
| Typical Turn-Off Delay Time | 60 ns |
| Rad Hard | No |
| Maximum Drain Source Voltage | 500 V |
| Typical Turn-On Delay Time | 6 ns |
| RDS-on | 600@10V mOhm |
| Supplier Package | TO-252 |
| Maximum Continuous Drain Current | 7.6 A |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Typical Fall Time | 7 ns |
| MSL Level | 3 |
| Product Dimensions | 6.73(Max) x 6.22(Max) x 2.41(Max) |
| Lead Finish | Matte Tin |
| Package | 3TO-252 |
| Replacement Part Number | PART-SPD08N50C3 |
| Weight | Contact us |
| Country of Origin | - |
