Please contact us for more photos of SQJ848AEP-T1-GE3
| Part Number | SQJ848AEP-T1-GE3 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 381710 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 40V 24A 5-Pin PowerPAK SO |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | SQJ848AEP-T1-GE3 |
| Datasheet download |  SQJ848AEP-T1-GE3.pdf |
| Part Number | SQJ848AEP-T1-GE3 |
|---|---|
| RDS-on | 7.6@10V MOhm |
| Operating Temperature | -55 to 175 °C |
| Rad Hard | No |
| Typical Turn-On Delay Time | 9 ns |
| Maximum Continuous Drain Current | 24 A |
| Typical Turn-Off Delay Time | 27 ns |
| Channel Mode | Enhancement |
| Mounting | Surface Mount |
| Typical Rise Time | 12 ns |
| Green | Yes |
| Lead Free | Yes |
| Maximum Drain Source Voltage | 40 V |
| Channel Type | N |
| Family | SQJ848AEP |
| Maximum Gate Source Voltage | ±20 V |
| Typical Fall Time | 9 ns |
| Screening Level | Automotive |
| Package | 5PowerPAK SO |
| Replacement Part Number | PART-SQJ848AEP-T1-GE3 |
| Weight | Contact us |
| Country of Origin | - |
