Please contact us for more photos of MP2161AGJ-Z
| Part Number | MP2161AGJ-Z |
|---|---|
| Manufacturer | MPS |
| Quantity in stock | 361770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 2.5V to 6V 8-Pin TSOT-23 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MP2161AGJ-Z |
| Datasheet download |  MP2161AGJ-Z.pdf |
| Part Number | MP2161AGJ-Z |
|---|---|
| Maximum Input Voltage | 6 V |
| Type | Step Down |
| Output Voltage | 0.6 to 6 V |
| Screening Level | Extended Industrial |
| Moisture Sensitivity Level | 1 |
| Operating Temperature | -40 to 125 °C |
| Rad Hard | No |
| Operating Supply Voltage | 2.5 to 6 V |
| Package Dimensions | 3 x 1.7 x 0.9 mm |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Minimum Input Voltage | 2.5 V |
| Switching Regulator | Yes |
| Output Type | Adjustable |
| Maximum Output Current | 2 A |
| Switching Frequency | 1200 to 1800 kHz |
| Pin Count | 8 |
| Supplier Package | TSOT-23 |
| Number of Outputs | 1 |
| Package | 8TSOT-23 |
| Replacement Part Number | PART-MP2161AGJ-Z |
| Weight | Contact us |
| Country of Origin | - |
