Please contact us for more photos of MP3216DJ-LF-Z
| Part Number | MP3216DJ-LF-Z |
|---|---|
| Manufacturer | MPS |
| Quantity in stock | 393240 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Up 2.5V 6V 6-Pin TSOT-23 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MP3216DJ-LF-Z |
| Datasheet download |  MP3216DJ-LF-Z.pdf |
| Part Number | MP3216DJ-LF-Z |
|---|---|
| Minimum Input Voltage | 2.5 V |
| Lead Finish | Matte Tin |
| Supplier Package | TSOT-23 |
| Rad Hard | No |
| Product Dimensions | 3(Max) x 1.7(Max) x 0.9(Max) |
| Operating Temperature | -40 to 85 °C |
| Switching Frequency | 1000 to 1500 kHz |
| Pin Count | 6 |
| Number of Outputs | 1 |
| Maximum Input Voltage | 6 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Type | Step Up |
| MSL Level | 1 |
| Maximum Output Current | 0.75 A |
| Output Type | Adjustable |
| Operating Supply Voltage | 2.5 to 6 V |
| Screening Level | Industrial |
| Switching Regulator | Yes |
| Output Voltage | 2.5 to 36 V |
| Package | 6TSOT-23 |
| Replacement Part Number | PART-MP3216DJ-LF-Z |
| Weight | Contact us |
| Country of Origin | - |
