Please contact us for more photos of MPQ4470GL-Z
| Part Number | MPQ4470GL-Z |
|---|---|
| Manufacturer | MPS |
| Quantity in stock | 572570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 36V 20-Pin QFN T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MPQ4470GL-Z |
| Datasheet download |  MPQ4470GL-Z.pdf |
| Part Number | MPQ4470GL-Z |
|---|---|
| Operating Supply Voltage | 4.5 to 36 V |
| Supplier Package | QFN |
| Operating Temperature | -40 to 125 °C |
| Output Type | Adjustable |
| Product Dimensions | 4 x 3 x 0.95(Max) |
| Output Voltage | 0.8 to 32.4 V |
| Pin Count | 20 |
| Rad Hard | No |
| Type | Step Down |
| Load Regulation | 2 % |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Minimum Input Voltage | 4.5 V |
| Switching Frequency | 200 to 1000 kHz |
| Maximum Input Voltage | 36 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Screening Level | Extended Industrial |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Maximum Output Current | 5 A |
| Package | 20QFN |
| Replacement Part Number | PART-MPQ4470GL-Z |
| Weight | Contact us |
| Country of Origin | - |
