Part Number 74CBTLV3126PW,118
Manufacturer Nexperia
Quantity in stock 150760 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Bus Switch 4-Element CMOS 4-IN 14-Pin TSSOP T R
Category Logic & Timing IC
Family Bus Switch
ROHS Compliant Yes
MSL Level 74CBTLV3126PW,118
Datasheet download 74CBTLV3126PW,118.pdf
Request Quotation for 74CBTLV3126PW,118

74CBTLV3126PW,118 Specifications

Part Number 74CBTLV3126PW,118
Maximum Operating Supply Voltage 3.6 V
Max Processing Temp 260
Propagation Delay Test Condition 50 pF
Fabrication Technology CMOS
Logic Family CBTLV
Product Dimensions 5.1 x 4.5 x 0.95 mm
Minimum Operating Supply Voltage 2.3 V
Maximum Propagation Delay Time @ Maximum CL 0.31@3V to 3.6V ns
Logic Function Bus Switch
Number of Inputs per Chip 4
Configuration 1 x 1:1
Maximum Low Level Output Current 128 mA
Maximum High Level Output Current -128 mA
Number of Elements per Chip 4
Maximum Quiescent Current 50 uA
Supplier Package TSSOP
Rad Hard No
Mounting Surface Mount
Pin Count 14
MSL Level 1
Number of Outputs per Chip 4
Operating Temperature -40 to 125 °C
Maximum On Resistance 8.4(Typ) Ohm
Lead Finish Gold
Typical Operating Supply Voltage 2.5|3.3 V
Package 14TSSOP
Replacement Part Number PART-74CBTLV3126PW,118
Weight Contact us
Country of Origin -
