Please contact us for more photos of UST1V220MDD
| Part Number | UST1V220MDD |
|---|---|
| Manufacturer | Nichicon |
| Quantity in stock | 762470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 35V 20% (6.3 X 7mm) Radial 2.5mm 57mA 1000 hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | UST1V220MDD |
| Datasheet download |  UST1V220MDD.pdf |
| Part Number | UST1V220MDD |
|---|---|
| Lead Finish | Matte Tin |
| Voltage(DC) | 35 V |
| Mounting | Through Hole |
| Capacitance Value | 22 uF |
| Lifetime | 1000 hr |
| Leakage Current | 3@2Min uA |
| Termination Style | Radial |
| Rad Hard | No |
| Product Dimensions | 7 mm |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Lead Pitch For Radial | 2.5 mm |
| Ripple Current | 57 mA |
| Operating Temperature | -55 to 105 °C |
| Package/Case | 6.3 X 7 |
| Product Diameter | 6.3 mm |
| Product Height | 7 mm |
| Replacement Part Number | PART-UST1V220MDD |
| Weight | Contact us |
| Country of Origin | - |
