Please contact us for more photos of APSF6R3EC3101MF05S
| Part Number | APSF6R3EC3101MF05S |
|---|---|
| Manufacturer | Nippon ChemiCon |
| Quantity in stock | 371250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 100uF 6.3V \u00b120% (6.3 X 5mm) Radial Aluminum Cylindrical Can 2.5mm 0.024 Ohm 2490mA 20000hr 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | APSF6R3EC3101MF05S |
| Datasheet download |  APSF6R3EC3101MF05S.pdf |
| Part Number | APSF6R3EC3101MF05S |
|---|---|
| Ripple Current | 2490 mA |
| Package Dimensions | 6.3 x 5 mm |
| Equivalent Series Resistance | 0.024 Ohm |
| Leakage Current | 500@2Min uA |
| Termination Style | Radial |
| Rad Hard | No |
| Mounting | Through Hole |
| Pin Count | 2 |
| Construction | Aluminum Cylindrical Can |
| Tolerance | ±20 % |
| Capacitance Value | 100 uF |
| Maximum Processing Temperature | 260 °C |
| Operating Temperature | -55 to 105 °C |
| Voltage(DC) | 6.3 Vdc |
| Lead Finish | Tin |
| Supplier Package | Radial |
| Lifetime | 20000 hr |
| Package/Case | 6.3 X 5 |
| Lead Pitch For Radial | 2.5 mm |
| Product Diameter | 6.3 mm |
| Product Height | 5 mm |
| Replacement Part Number | PART-APSF6R3EC3101MF05S |
| Weight | Contact us |
| Country of Origin | - |
