Please contact us for more photos of MK22FN1M0AVMC12
| Part Number | MK22FN1M0AVMC12 |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 428000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit K22 ARM Cortex M4 RISC 1MB Flash 3.3V 121-Pin MAPBGA Tray |
| Category | Microcontrollers MCU IC |
| Family | 32 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MK22FN1M0AVMC12 |
| Datasheet download |  MK22FN1M0AVMC12.pdf |
| Part Number | MK22FN1M0AVMC12 |
|---|---|
| Rad Hard | No |
| Instruction Set Architecture | RISC |
| Operating Supply Voltage | 3.3 V |
| Mounting | Surface Mount |
| Data Bus Width | 32 Bit |
| Special Features | CAN Controller |
| Analog Comparators | 3 |
| Max Processing Temp | 260 |
| Minimum Operating Supply Voltage | 1.71 V |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 105 °C |
| Supplier Package | MAPBGA |
| Program Memory Size | 1 MB |
| MSL Level | 3 |
| Maximum Operating Supply Voltage | 3.6 V |
| Number of Programmable I/Os | 86 |
| RAM Size | 128 KB |
| Product Dimensions | 8 x 8 x 1.27(Max) |
| Pin Count | 121 |
| Program Memory Type | Flash |
| Device Core | ARM Cortex M4 |
| Lead Finish | Tin|Silver|Copper |
| Number of Timers | 6 |
| Maximum Speed | 120 MHz |
| Watchdog | 1 |
| Interface Type | CAN/I2C/I2S/SPI/UART/USB |
| Package | 121MAPBGA |
| Replacement Part Number | PART-MK22FN1M0AVMC12 |
| Weight | Contact us |
| Country of Origin | - |
