Please contact us for more photos of MKE04Z8VWJ4R
| Part Number | MKE04Z8VWJ4R |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 533600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit KE04 ARM Cortex M0+ RISC 8KB Flash 3.3V 5V 20-Pin SOIC W T R |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MKE04Z8VWJ4R |
| Datasheet download |  MKE04Z8VWJ4R.pdf |
| Part Number | MKE04Z8VWJ4R |
|---|---|
| Program Memory Type | Flash |
| Minimum Operating Supply Voltage | 2.7 V |
| Number of Timers | 4 |
| Lead Finish | Matte Tin |
| Interface Type | I2C/SPI/UART |
| Pin Count | 20 |
| Program Memory Size | 1 KB |
| Watchdog | 1 |
| Rad Hard | No |
| Number of Programmable I/Os | 18 |
| Mounting | Surface Mount |
| Operating Supply Voltage | 3.3|5 V |
| RAM Size | 0.125 KB |
| Device Core | ARM Cortex M0+ |
| Maximum Operating Supply Voltage | 5.5 V |
| Data Bus Width | 32 Bit |
| Screening Level | Extended Industrial |
| Maximum Speed | 48 MHz |
| Maximum Processing Temperature | 260 °C |
| Instruction Set Architecture | RISC |
| Moisture Sensitivity Level | 3 |
| Operating Temperature | -40 to 105 °C |
| Supplier Package | SOIC W |
| Package Dimensions | 12.95 x 7.6 x 2.4 mm |
| On-Chip ADC | 12-chx12-bit |
| Analog Comparators | 2 |
| Package | 20SOIC W |
| Replacement Part Number | PART-MKE04Z8VWJ4R |
| Weight | Contact us |
| Country of Origin | - |
