Please contact us for more photos of MKL36Z256VLL4R
| Part Number | MKL36Z256VLL4R |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 647160 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit KL3x ARM Cortex M0+ RISC 256KB Flash 1.8V 2.5V 3.3V 100 -Pin LQFP T R |
| Category | Microcontrollers MCU IC |
| Family | 32 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MKL36Z256VLL4R |
| Datasheet download |  MKL36Z256VLL4R.pdf |
| Part Number | MKL36Z256VLL4R |
|---|---|
| Device Core | ARM Cortex M0+ |
| Data Bus Width | 32 Bit |
| Minimum Operating Supply Voltage | 1.71 V |
| Maximum Speed | 48 MHz |
| Screening Level | Extended Industrial |
| Pin Count | 100 |
| Special Features | LCD Controller |
| Display Driver | 1 |
| Analog Comparators | 1 |
| Operating Temperature | -40 to 105 °C |
| MSL Level | 3 |
| Instruction Set Architecture | RISC |
| Rad Hard | No |
| Mounting | Surface Mount |
| RAM Size | 32 KB |
| Max Processing Temp | 260 |
| Number of Timers | 4 |
| Supplier Package | LQFP |
| Operating Supply Voltage | 1.8|2.5|3.3 V |
| Maximum Operating Supply Voltage | 3.6 V |
| Program Memory Size | 256 KB |
| Program Memory Type | Flash |
| Number of Programmable I/Os | 84 |
| Lead Finish | Matte Tin |
| LCD Segments | 204|376 |
| Interface Type | I2C/I2S/SPI/UART |
| Watchdog | 1 |
| Product Dimensions | 14 x 14 x 1.4 |
| Package | 100LQFP |
| Replacement Part Number | PART-MKL36Z256VLL4R |
| Weight | Contact us |
| Country of Origin | - |
