Please contact us for more photos of MPC8536BVJAVLA
| Part Number | MPC8536BVJAVLA |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 422290 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MPU MPC85xx RISC 32-Bit 1500MHz 1.5V 1.8V 2.5V 3.3V 783-Pin FC-BGA Tray |
| Category | Processor IC |
| Family | Processors |
| ROHS Compliant | Yes |
| MSL Level | MPC8536BVJAVLA |
| Datasheet download |  MPC8536BVJAVLA.pdf |
| Part Number | MPC8536BVJAVLA |
|---|---|
| Number of CPU Cores | 1 |
| RAM Size | 512 KB |
| I/O Voltage | 1.5|1.8|2.5|3.3 V |
| Maximum Speed | 1500 MHz |
| Lead Finish | Tin|Silver|Copper |
| Interface Type | I2C/SPI/UART |
| Supplier Package | FCBGA |
| Pin Count | 783 |
| Operating Temperature | 0 to 105 °C |
| Rad Hard | No |
| Operating Supply Voltage | 1|2.5|3.3 V |
| Instruction Set Architecture | RISC |
| Product Dimensions | 29 x 29 x 2.2(Max) |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Data Bus Width | 32 Bit |
| Device Core | e500 |
| Fabrication Technology | 0.09um |
| Mounting | Surface Mount |
| Package | 783FC-BGA |
| Replacement Part Number | PART-MPC8536BVJAVLA |
| Weight | Contact us |
| Country of Origin | - |
