Please contact us for more photos of S9S12G128F0MLLR
| Part Number | S9S12G128F0MLLR |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 550060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-Bit S12 CISC 128KB Flash 3.3V 5V 100-Pin LQFP T R |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | S9S12G128F0MLLR |
| Datasheet download |  S9S12G128F0MLLR.pdf |
| Part Number | S9S12G128F0MLLR |
|---|---|
| Rad Hard | No |
| Program Memory Size | 128 KB |
| Mounting | Surface Mount |
| Operating Supply Voltage | 3.3|5 V |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Maximum Operating Supply Voltage | 5.5 V |
| Pin Count | 100 |
| Operating Temperature | -40 to 125 °C |
| Program Memory Type | Flash |
| Number of Programmable I/Os | 86 |
| Watchdog | 1 |
| Number of Timers | 1 |
| Supplier Package | LQFP |
| Instruction Set Architecture | CISC |
| RAM Size | 8 KB |
| Screening Level | Automotive |
| Minimum Operating Supply Voltage | 3.13 V |
| Product Dimensions | 14 x 14 x 1.4 |
| Data Bus Width | 16 Bit |
| Special Features | CAN Controller |
| On-Chip ADC | 12-chx10-bit |
| Interface Type | CAN/SCI/SPI |
| Maximum Speed | 25 MHz |
| Lead Finish | Matte Tin |
| Data Memory Size | 4 KB |
| Analog Comparators | 1 |
| Package | 100LQFP |
| Replacement Part Number | PART-S9S12G128F0MLLR |
| Weight | Contact us |
| Country of Origin | - |
