Please contact us for more photos of LM2596DSADJR4G
| Part Number | LM2596DSADJR4G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 162280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 40V 6-Pin(5+Tab) D2PAK T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | LM2596DSADJR4G |
| Datasheet download |  LM2596DSADJR4G.pdf |
| Part Number | LM2596DSADJR4G |
|---|---|
| Operating Supply Voltage | 4.5 to 40 V |
| MSL Level | 1 |
| Rad Hard | No |
| Output Voltage | 1.23 to 37 V |
| Type | Step Down |
| Number of Outputs | 1 |
| Maximum Input Voltage | 40 V |
| Switching Regulator | Yes |
| Pin Count | 6 |
| Minimum Input Voltage | 4.5 V |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Efficiency | 73 % |
| Lead Finish | Matte Tin |
| Operating Temperature | -40 to 125 °C |
| Supplier Package | D2PAK |
| Product Dimensions | 10.24 x 9.35 x 4.57 mm |
| Maximum Output Current | 3 A |
| Output Type | Adjustable |
| Switching Frequency | 165 kHz |
| Package | 6D2PAK |
| Replacement Part Number | PART-LM2596DSADJR4G |
| Weight | Contact us |
| Country of Origin | - |
