Please contact us for more photos of NCP5109ADR2G
| Part Number | NCP5109ADR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 349580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MOSFET DRVR 0.5A 1-OUT Hi Lo Sid 8-Pin SOIC T R |
| Category | Power Management IC |
| Family | MOSFET and Power Drivers |
| ROHS Compliant | Yes |
| MSL Level | NCP5109ADR2G |
| Datasheet download |  NCP5109ADR2G.pdf |
| Part Number | NCP5109ADR2G |
|---|---|
| Rad Hard | No |
| Peak Output Current | 0.5 A |
| Number of Outputs | 1 |
| Bridge Type | Half Bridge |
| Output Resistance | 60 Ohm |
| Supplier Package | SOIC |
| Input Logic Compatibility | 3V|5V |
| Driver Configuration | Non-Inverting |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Screening Level | Extended Industrial |
| High and Low Sides Dependency | Independent |
| MSL Level | 1 |
| Maximum Fall Time | 75 ns |
| Maximum Turn-On Delay Time | 170 ns |
| Typical Operating Supply Voltage | 15 V |
| Operating Temperature | -40 to 125 °C |
| Pin Count | 8 |
| Maximum Supply Current | 5 mA |
| Lead Finish | Pure Tin |
| Minimum Operating Supply Voltage | 10 V |
| Product Dimensions | 5(Max) x 4(Max) x 1.5(Max) |
| Maximum Turn-Off Delay Time | 170 ns |
| Driver Type | High and Low Side |
| Maximum Rise Time | 160 ns |
| Number of Drivers | 1 |
| Maximum Propagation Delay Time | 35 ns |
| Maximum Operating Supply Voltage | 20 V |
| Package | 8SOIC |
| Replacement Part Number | PART-NCP5109ADR2G |
| Weight | Contact us |
| Country of Origin | - |
