GF CSHPM1.24-2S3S-1-0-350-R18 OSRAM Opto Semiconductors

Please contact us for more photos of GF CSHPM1.24-2S3S-1-0-350-R18

Part Number	GF CSHPM1.24-2S3S-1-0-350-R18
Manufacturer	OSRAM Opto Semiconductors
Quantity in stock	337650 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Red 250mW 730nm Chip LED 3-Pin CSMD T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	GF CSHPM1.24-2S3S-1-0-350-R18
Datasheet download	GF CSHPM1.24-2S3S-1-0-350-R18.pdf

Request Quotation for GF CSHPM1.24-2S3S-1-0-350-R18

GF CSHPM1.24-2S3S-1-0-350-R18 Specifications

Part Number	GF CSHPM1.24-2S3S-1-0-350-R18
Number of LEDs	1
Moisture Sensitivity Level	2
Lens Dimensions	2.14 x 0.95
Type	Uni-Color
Maximum Processing Temperature	260
Lead Finish	Matte Tin
Reverse Voltage	1.2
Supplier Package	CSMD
Maximum Forward Voltage per Color	2.3
Package Dimensions	3.1 x 3.1 x 1.58
Mounting Orientation	Top Mount
Luminous Flux	250
Rad Hard	No
Viewing Angle	150
Mounting	Surface Mount
Category	Chip LED
Screening Level	Extended Industrial
Color	Red
Maximum Forward Current	1000
Operating Temperature	-40 to 120 °C
Dominant Wavelength	730
Peak Wavelength	730
Pin Count	3
Lens Shape Type	Domed
Package	3CSMD
Replacement Part Number	PART-GF CSHPM1.24-2S3S-1-0-350-R18
Weight	Contact us
Country of Origin	-
