LO M67F-V1AA-34 OSRAM Opto Semiconductors

Please contact us for more photos of LO M67F-V1AA-34

Part Number	LO M67F-V1AA-34
Manufacturer	OSRAM Opto Semiconductors
Quantity in stock	145610 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Orange 3.78lm 610nm Chip LED 2-Pin SMD T R
Category	Lighting
Family	HB LEDs
ROHS Compliant	Yes
MSL Level	LO M67F-V1AA-34
Datasheet download	LO M67F-V1AA-34.pdf

Request Quotation for LO M67F-V1AA-34

LO M67F-V1AA-34 Specifications

Part Number	LO M67F-V1AA-34
Category	Chip LED
Rad Hard	No
Lead Finish	Matte Tin
Mounting	Surface Mount
Maximum Forward Voltage per Color	2.5 V
Maximum Forward Current	30 mA
Reverse Voltage	12 V
Product Dimensions	1.5(Max) x 2.3(Max) x 1.25(Max)
Operating Temperature	-40 to 100 °C
Supplier Package	SMD
Number of LEDs	1
Mounting Orientation	Top Mount
Type	Chip LED
Screening Level	Extended Industrial
Viewing Angle	120 °
Max Processing Temp	260
Peak Wavelength	610 nm
Lens Dimensions	1.5 x 1 x 0.8(Max) mm
MSL Level	2
Luminous Flux	3.78 lm
Pin Count	2
Package	2SMD
Replacement Part Number	PART-LO M67F-V1AA-34
Weight	Contact us
Country of Origin	-
