Please contact us for more photos of 2TPSF270M6E
| Part Number | 2TPSF270M6E |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 299800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 270uF 2V B2S CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528,B2S 0.006 Ohm 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | 2TPSF270M6E |
| Datasheet download |  2TPSF270M6E.pdf |
| Part Number | 2TPSF270M6E |
|---|---|
| Supplier Package | 1411 |
| Package/Case | 3528,B2S |
| Rad Hard | No |
| Case Style | Molded |
| Pin Count | 2 |
| Tolerance | 20 % |
| Dissipation Factor | 8 % |
| Equivalent Series Resistance | 0.006 Ohm |
| Case Size | 1411 |
| Operating Temperature | -55 to 105 °C |
| Construction | Flat |
| Voltage(DC) | 2 V |
| Polarity | Polar |
| Mounting | Surface Mount |
| Lead Finish | Palladium|Gold |
| Capacitance Value | 270 uF |
| Max Processing Temp | 250|260 |
| MSL Level | 5 |
| Leakage Current | 108@5Min uA |
| Case Code | B2S |
| Product Depth | 2.8 mm |
| Product Height | 1.9 mm |
| Product Length | 3.5 mm |
| Replacement Part Number | PART-2TPSF270M6E |
| Weight | Contact us |
| Country of Origin | - |
