Please contact us for more photos of AXE5E4026
| Part Number | AXE5E4026 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 732370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board SKT 40 POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXE5E4026 |
| Datasheet download |  AXE5E4026.pdf |
| Part Number | AXE5E4026 |
|---|---|
| Termination Method | Solder |
| Mounting | Surface Mount |
| Pitch | 0.4 mm |
| Body Orientation | Straight |
| Pin Count | 40 |
| Product Dimensions | 10.5 x 2.2 x 0.77 |
| Gender | SKT |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Lead Finish | Gold Over Nickel |
| Operating Temperature | -55 to 85 °C |
| Max Processing Temp | 260 |
| Housing Material | Liquid Crystal Polymer |
| Product Depth | 2.2 mm |
| Product Height | 0.77 mm |
| Product Length | 10.5 mm |
| Replacement Part Number | PART-AXE5E4026 |
| Weight | Contact us |
| Country of Origin | - |
