Please contact us for more photos of AXE664124D
| Part Number | AXE664124D |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 590550 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board HDR 64 POS 0.4mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXE664124D |
| Datasheet download |  AXE664124D.pdf |
| Part Number | AXE664124D |
|---|---|
| Contact Plating | Gold Over Nickel |
| Number of Contacts | 64 |
| Housing Material | Liquid Crystal Polymer |
| Pitch | 0.4 mm |
| Operating Temperature | -55 to 85 °C |
| Number of Rows | 2 |
| Type | Board to Board |
| Gender | HDR |
| Maximum Contact Resistance | 90 MOhm |
| Maximum Voltage Rating | 60 Vdc |
| Termination Method | Solder |
| Rad Hard | No |
| Contact Material | Copper Alloy |
| Lead Finish | Gold Over Nickel |
| Pin Count | 64 |
| Package Dimensions | 14.6 x 1.42 x 0.65 mm |
| Body Orientation | Straight |
| Maximum Current Rating | 0.3 A |
| Mounting | Surface Mount |
| Maximum Processing Temperature | 260 °C |
| Product Depth | 1.42 mm |
| Product Height | 0.65 mm |
| Product Length | 14.6 mm |
| Replacement Part Number | PART-AXE664124D |
| Weight | Contact us |
| Country of Origin | - |
