Please contact us for more photos of ECHU1C563JX5
| Part Number | ECHU1C563JX5 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 117410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.056uF 16V PPS 5% (3.2 X 2.5 X 1.5mm) SMD 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECHU1C563JX5 |
| Datasheet download |  ECHU1C563JX5.pdf |
| Part Number | ECHU1C563JX5 |
|---|---|
| Construction | Flat |
| Mounting | Surface Mount |
| Capacitance Value | 0.056 uF |
| Product Dimensions | 3.2 x 2.5 x 1.5 mm |
| Voltage(DC) | 16 V |
| Operating Temperature | -55 to 125 °C |
| Dielectric | PPS |
| Dielectric Material | |
| Package/Case | 1210 |
| Case Size | 1210 |
| Lead Finish | Tin/Silver/Copper |
| Tolerance | 5 % |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Product Depth | 2.5 mm |
| Product Height | 1.5 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-ECHU1C563JX5 |
| Weight | Contact us |
| Country of Origin | - |
