Please contact us for more photos of ECHU1H471JX5
| Part Number | ECHU1H471JX5 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 306000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 470pF 50V PPS 5% (2 X 1.25 X 0.9mm) SMD 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECHU1H471JX5 |
| Datasheet download |  ECHU1H471JX5.pdf |
| Part Number | ECHU1H471JX5 |
|---|---|
| Dielectric Material | |
| Voltage(DC) | 50 V |
| Lead Finish | Tin/Silver/Copper |
| Rad Hard | No |
| Package/Case | 0805 |
| Max Processing Temp | 260 |
| Tolerance | 5 % |
| Construction | Flat |
| Capacitance Value | 470 pF |
| Operating Temperature | -55 to 125 °C |
| Mounting | Surface Mount |
| Case Size | 0805 |
| Product Dimensions | 2 x 1.25 x 0.9 mm |
| Dielectric | PPS |
| Product Depth | 1.25 mm |
| Product Height | 0.9 mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-ECHU1H471JX5 |
| Weight | Contact us |
| Country of Origin | - |
