Please contact us for more photos of ECHU1H562GX5
| Part Number | ECHU1H562GX5 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 474070 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.0056uF 50V PPS 2% (3.2 X 1.6 X 0.9mm) SMD 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECHU1H562GX5 |
| Datasheet download |  ECHU1H562GX5.pdf |
| Part Number | ECHU1H562GX5 |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 260 |
| Lead Finish | Tin/Silver/Copper |
| Dielectric Material | |
| Product Dimensions | 3.2 x 1.6 x 0.9 mm |
| Voltage(DC) | 50 V |
| Case Size | 1206 |
| Construction | Flat |
| Package/Case | 1206 |
| Mounting | Surface Mount |
| Capacitance Value | 0.0056 uF |
| Dielectric | PPS |
| Tolerance | 2 % |
| Type | Flat |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 1.6 mm |
| Product Height | 0.9 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-ECHU1H562GX5 |
| Weight | Contact us |
| Country of Origin | - |
