Please contact us for more photos of ECQE2473KF3
| Part Number | ECQE2473KF3 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 588340 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.047uF 250V PET 10% (10.3 X 4.5 X 12.5mm) Radial 5mm 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECQE2473KF3 |
| Datasheet download |  ECQE2473KF3.pdf |
| Part Number | ECQE2473KF3 |
|---|---|
| Mounting | Through Hole |
| Termination Style | Radial |
| Lead Pitch For Radial | 5 mm |
| Type | Radial |
| Rad Hard | No |
| Seated Plane Height | 12.5 mm |
| Tolerance | 10 % |
| Package/Case | 10.3(Max) X 4.5(Max) X 12.5(Max) |
| Voltage(DC) | 250 V |
| Max Processing Temp | 250 to 260 |
| Lead Finish | Tin |
| Dielectric | PET |
| Product Dimensions | 10.3 x 4.5 x 12.5 mm |
| Operating Temperature | -40 to 105 °C |
| Dielectric Material | PET |
| Capacitance Value | 0.047 uF |
| Product Depth | 4.5(Max) mm |
| Product Height | 12.5(Max) mm |
| Product Length | 10.3(Max) mm |
| Replacement Part Number | PART-ECQE2473KF3 |
| Weight | Contact us |
| Country of Origin | - |
