Please contact us for more photos of ECWF6104JL
| Part Number | ECWF6104JL |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 123520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.1uF 630V PP 5% (18 X 7.7 X 12.1mm) Radial 15mm 105\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECWF6104JL |
| Datasheet download |  ECWF6104JL.pdf |
| Part Number | ECWF6104JL |
|---|---|
| Lead Pitch For Radial | 15 mm |
| Capacitance Value | 0.1 uF |
| Seated Plane Height | 13.6 mm |
| Operating Temperature | -40 to 105 °C |
| Package/Case | 18(Max) X 7.7(Max) X 12.1(Max) |
| Mounting | Through Hole |
| Termination Style | Radial |
| Product Dimensions | 18 x 7.7 x 12.1 mm |
| Type | Radial |
| Voltage(DC) | 630 V |
| Lead Finish | Tin |
| Rad Hard | No |
| Tolerance | 5 % |
| Max Processing Temp | 250 to 260 |
| Dielectric | PP |
| Product Depth | 7.7(Max) mm |
| Product Height | 12.1(Max) mm |
| Product Length | 18(Max) mm |
| Replacement Part Number | PART-ECWF6104JL |
| Weight | Contact us |
| Country of Origin | - |
