ECWFD2W225K Panasonic

ECWFD2W225K Images

Please contact us for more photos of ECWFD2W225K

Part Number	ECWFD2W225K
Manufacturer	Panasonic
Quantity in stock	499920 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Cap Film 2.2uF 450V PP 10% (17.5 X 11.1 X 14.3mm) Radial 15mm 110\u00b0C Bulk
Category	Capacitors
Family	Capacitor Film
ROHS Compliant	Yes
MSL Level	ECWFD2W225K
Datasheet download	ECWFD2W225K.pdf

Request Quotation for ECWFD2W225K

ECWFD2W225K Specifications

Part Number	ECWFD2W225K
Voltage(DC)	450 V
Pin Count	2
Construction	Radial
Product Dimensions	17.5(Max) x 11.1(Max) x 14.3(Max)
Termination Style	Radial
Package/Case	17.5(Max) X 11.1(Max) X 14.3(Max)
Capacitance Value	2.2 uF
Tolerance	10 %
Supplier Package	Radial
Operating Temperature	-40 to 110 °C
Rad Hard	No
Lead Finish	Tin
Seated Plane Height	14.3 mm
Lead Pitch For Radial	15 mm
Mounting	Through Hole
Product Depth	11.1(Max) mm
Product Height	14.3(Max) mm
Product Length	17.5(Max) mm
Replacement Part Number	PART-ECWFD2W225K
Weight	Contact us
Country of Origin	-
