Please contact us for more photos of EEFCD0G101R
| Part Number | EEFCD0G101R |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 464480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 100uF 4V 20% (7.3 X 4.3 X 1.8mm) SMD 0.018 Ohm 2500mA 1000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEFCD0G101R |
| Datasheet download |  EEFCD0G101R.pdf |
| Part Number | EEFCD0G101R |
|---|---|
| Package/Case | 7.3 X 4.3 X 1.8 |
| Construction | Flat |
| Mounting | Surface Mount |
| Ripple Current | 2500 mA |
| Max Processing Temp | 240 |
| Operating Temperature | -40 to 105 °C |
| Lead Finish | Tin |
| Voltage(DC) | 4 V |
| Capacitance Value | 100 uF |
| Product Dimensions | 7.3 x 4.3 x 1.8 mm |
| Rad Hard | No |
| Equivalent Series Resistance | 0.018 Ohm |
| Tolerance | 20 % |
| Product Depth | 4.3 mm |
| Product Height | 1.8 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-EEFCD0G101R |
| Weight | Contact us |
| Country of Origin | - |
